AEMC DTR 8510 User Manual

12 Digital Transformer Ratiometer DTR
®
Model 8510
3.2 Battery Charger Specifications
DTR
®
8510 BATTERY CHARGER
ELECTRICAL
No-load Voltage
41V ±2V
Fast Charge Current
0.9A ±70mA
Top-off Charge
130mA ±40mA
Charge Termination Options
-dV, dT/dt
Input Rating
90 to 264V
AC /47 to 63Hz
Maximum Output Power
35W
Trickle Charge Current
50mA ±25mA
Leakage Current
(from battery with mains off)
<1mA
MECHANICAL
Dimensions
4.22 x 2.64 x 1.44" (107 x 67 x 36.5mm)
Weight
0.55 lbs (250g)
Input Connection
2-pin IEC 320-C7
Output Connection
NiMH: 3 PIN DIN
ENVIRONMENTAL
Operating Temperature
-4° to 104°F (-20° to 40°C)
SAFETY
Insulation Class
II
Electrical Safety Approval
EN 60601-1, EN 60950, EN 60335-2-29
EMC Standards
EN 61000-6-3 (Emission), EN 61000-6-1 (Immunity)
Specications are subject to change without notice.
www.ShopAEMC.com
Shop for AEMC products online at:
1.877.766.5412
