AEMC DTR 8510 User Manual

Digital Transformer Ratiometer DTR
®
Model 8510 45
7.3 Using the Control Panel
TheControl Panelisusedforinstrumentoperationandconguration.
ToopentheControlPanelreferto§7.2.
Figure 7-7
Themainmenuatthetopofthescreenliststhefollowingcommands:
File
Open -
OpensaDTR*.icple
Save - Savesthereportleintheappropriatefolder
Save as - Permitstheusertosavethereportatthelocationofhis
choice
Create DataView Report -
Generatesreportfortheopentestresults
Print Test - Printstheresultofthetest
Print Preview -Providesapreviewoftheselectedtesttobeprinted
Print All Tests - PrintsallthetestsintheselectedObject
Print - Printstheselectedreal-timewindow
Print Preview All Tests -Providesapreviewofallteststobeprinted
Print Setup - DisplaysaPrintSetupwindowallowingyoutoselecta
destinationprinterandchangevariousprintingoptions
Exit - Closesthecontrolpanel
