AEMC DTR 8510 User Manual

Digital Transformer Ratiometer DTR
®
Model 8510 13
CHAPTER 4
DISPLAY FUNCTIONS
4.1 Program Flow
Inordertousetheinstrumentefciently,itisimportanttounderstandthe
programow.
• Pressingthe▼and▲keyssimultaneouslyallowsgoingupone
level(ifthereisalevel)intheprogramow.
(Verticalnavigationmovingupalevel).
• Pressingthe▼or▲keyallowsnavigationwithinthelevel.
(Horizontalnavigation).
• PressingtheENTERkeyallowstheselectionanddisplayofchoices
onelevelbelow(ifthereisalevel)intheprogramow.
(Verticalnavigationmovingdownalevel).
4.2 Top Level Menu
TheinstrumenthasatoplevelcontrolasshowninFig.4-1.
Theusercannavigatearoundtheringbypressingthe▼or▲key.
Main Screen
Recall Data
Configuration
Figure 4-1
Oncetheinstrumentisturnedon,itinitializesandthendisplaystheMain
Screen:
Figure 4-2
