AEMC DTR 8510 User Manual

Digital Transformer Ratiometer DTR
®
Model 8510 7
The DTR
®
8510 will display the following messages:
•
IncorrectLeadConnections
• H/XReversal(accidentalstep-upmisconnection)
• Short(excessexcitationcurrent)
• OpenCircuits
• CircuitContinuity
• LowBattery
Inaddition,theDTR
®
8510allowstheusertostorethedatainautomatic
ormanualmodeaftereachtesteliminatingtheneedtowritedownthetest
results. Each measurement record is date and time stamped providing
completetestinformation.
TheusercanalsosaveNameplatevoltagesandcomparetheresultsas
thedataisbeinggathered.ThedatacanlaterbedownloadedtoaPCand
analyzedusingtheDataView
®
softwarepackagewhichisincludedwith
theproduct.
DataView
®
allowsfullcontroloftheinstrument.
The DTR
®
8510 utilizes an advanced, low-voltage, step-down measure-
ment technique in which the high voltage “H” windings are subjected to
test excitation. This results in greater operator safety and the ability to
test a much wider array of transformer types and sizes.
