AERMEC Multichiller-Evo - Installer - pCOe Analogue Inputs

25
INSTALLER - Inputs/Outputs - Status of pCOe analogue inputs
A
B
C

Index Meaning
1
Actual temperature value detected by the NTC probe connected to analogue input B1 on the pCOe
expansion board;
2
Actual temperature value detected by the NTC probe connected to analogue input B2 on the pCOe
expansion board;
3
Actual temperature value detected by the NTC probe connected to analogue input B3 on the pCOe
expansion board;
4
Actual temperature value detected by the NTC probe connected to analogue input B4 on the pCOe
expansion board;
ACTIONS
AVAILABLE:
1
A C D
2
3
4


B
INSTALLER - Inputs/Outputs - Status of pCOe digital inputs
A
B
C

Index Meaning
1 Not used
2 Not used
3 Not used
4 Not used
ACTIONS
AVAILABLE:
1
A C D
2
3
4


B
D

D

