37
INSTALLER - Charts - Temperature probe seng for charts values
A
B
Index Meaning
1 Indicates which temperature probes are used for the charts (system side)
2 Indicates which temperature probes are used for the charts (recovery side)
ACTIONS
AVAILABLE:
A B
1
2
INSTALLER - Chillers network - Set of the connected chillers (Page 1)
A
C
Index Meaning
1
Indicates the modbus library used to communicate with the network chillers; the number on the
left indicates the chiller to which we refer. If you want to add a chiller, you must specify the correct
library to be used for serial communication. However, if a chiller is added at a later stage, the overall
management needs to be “xed threshold” since, in order to use the optimised managements, it is
necessary to load the specic data of the units on the Multichiller-Evo (for more information, contact
the after-sales service/assistance)
2 Indicates the modbus address to be assigned to each chiller
3 Indicates, only for the NSM units working in master/slave mode, the chiller slave 1 address
4 Indicates, only for the NSM units working in master/slave mode, the chiller slave 2 address
5 Indicates, only for the NSM units working in master/slave mode, the chiller slave 3 address
ACTIONS
AVAILABLE:
B
D
E
F
G
H
1
D
A CB
E F G H
2 3 4 5
To Next Page
