31
16 CHILLER MENU
The Chiller menu makes it possible to identify the machine status and change the
general enabling.
16.1 OPERATING MODE MONITOR
7.0 °C
Working mode
Cooling
Current setpoint
— Selection of operational mode
— Actual setpoint in use for adjustment
NB: some icons can appear at the bottom of this window, indicating cer-
tain system states:
—
: system chilled water production;
— : system hot water production.
16.2 MAIN SETPOINT MONITORS
50.0 °C
07.0 °C
Cooling setpoint
Heating setpoint
— Setting of cooling set
— Setting of heating set (enabled for heat pump machine)
16.3 DOUBLE SET SETTING MONITOR
45.0 °C
11.0 °C
Cooling double
setpoint
Heating double
setpoint
— Double cooling set setting (window enabled if the double setpoint is enabled
see the manufacturer menu)
— Double heating set setting (window enabled if the double setpoint is enabled
see the manufacturer menu)
16.4 CURRENT SETPOINT MONITOR
10.0 °C
100 %
000 %--
Current setpoint
Limit
Ext. Demand
— Setpoint currently used, selected from those possible (hot, cold, double hot,
double cold, multifunction input, serial)
— Limit: Limit of the power, owing to serial or multifunction input request
— The string Ext demand is visible only if the Supervisor demand function is en-
abled
— The symbol >> indicates that communication is active, and the percentage g-
ure of requested power is valid.
16.5 MULTIFUNCTION INPUT MONITOR A
000.0 °C
007.0 °C
045.0 °C
On
Multifunction
Input
Cooling Setp
Heating Setp
— Multifunction input enabled for setpoint setting
— Input value in the size selected
— Cooling setpoint set from multifunction input
— Heat Setpoint set from multifunction input
16.6 MULTIFUNCTION INPUT MONITOR B
000.0 °C
000 %
On
Multifunction
Input
Power Limit
— Multifunction input enabled for cooling capacity limitation
— Input value in the size selected
— Maximum limit of the cooling capacity expressed as a percentage
