36
18.20 NTC PROBE TEMPERATURE MONITOR
20.0 °C
35.0 °C
Probe 7 cong.
NTC Type
Temp. Low
Temp. High
NTC type multifunction input enabled (MASTER ONLY)
NTC probe minimum temperature
NTC probe maximum temperature
18.21 INPUT VOLTAGE MONITOR
00.0 V
10.0 V
Probe 7 cong.
Volt Low
Volt High
0-10 Volt Type
0 –10 volt type multifunction input enabled (MASTER ONLY)
Minimum input voltage
Maximum input voltage
18.22 INPUT CURRENT MONITOR
04.0 mA
4-20 mA
mA
mA
20.0 mA
Probe 7 cong.
Low
High
Type
4 -20mA type multifunction input enabled (MASTER ONLY)
Minimum input current
Maximum input current
18.23 COOLING SETPOINT MONITOR
07.0 °C
12.0 °C
Probe 7 cong.
Cool Set Low
Cool Set High
External Setpoint
Multifunction input enabled with Setpoint function (MASTER ONLY )
Cooling setpoint corresponding to the minimum size of the input
Cooling setpoint corresponding to the maximum size of the input
18.24 HEATING SETPOINT MONITOR
45.0 °C
50.0 °C
Probe 7 cong.
Heat Set Low
Heat Set High
External Setpoint
Multifunction input enabled with Setpoint function (MASTER ONLY )
Heating setpoint corresponding to the minimum size of the input
Heating setpoint corresponding to the maximum size of the input
18.25 MULTIFUNCTION INPUT WITH COOLING CAPACITY
LIMIT MONITOR
000 %
100 %
Probe 7 cong.
Limit Low
Limit High
External Limit
Multifunction input enabled with cooling capacity limit function (MASTER ON-
LY )
Power limit corresponding to the minimum size of the input
Power limit corresponding to the maximum size of the input
