17
9.2 INSTALLER MENU
This menu contains the parameters necessary for the machine conguration and
its functions.
Password monitor to access the installer menu
Enter the password to access the menu (the password is 0000).
03/12/21
10:33:04
1
****
Cancel
Ok
SETTINGS
Installer
Probe and transducer enabling monitor
1
1/8 10:35:11
B1 B2
B3 B4
B5 B6
B7 B8
B9 B10
INSTALLER
Probe and transducer presence enabling:
— B1: High pressure transducer
— B2: Low pressure transducer
— B3: evaporator water inlet temperature probe (master only)
— B3: common water inlet temperature probe (in case of adjustment at the outlet
with multiple parallel connected evaporators) (slave 1 only)
— B4: Discharge gas temperature probe
— B5: evaporator water outlet temperature probe
— B6: Ammeter transformer
— B7: Multifunction input
Warning: if used as the multifunction input, do not enable (B7)
— B8: evaporator input gas temperature probe
— B9 (SUWH)
— B10 (SIWH)
High and low pressure transducer limit monitor
1
2/8 10:35:11
0.0
0.0 10.0
30.0
4.20 mA
4.20 mA
bar
bar
bar
bar
20 mA
20 mA
4 mA
4 mA
INSTALLER
Low Pressure Probe Conguration
High Pressure Probe Conguration
— Full scale limits for high pressure transducer 4-20mA.
— Full scale limits for low pressure transducer 4-20mA.
Digital input and supervisor command enabling monitor
2
3/8 10:38:37
INSTALLER
Evaporator Pump
Circuit Breaker
Pump O With
Compressor
Enable Double
Setpoint
Heating/Cooling
By Supervisor
Heating/Cooling
by Digital Input
Demand by
Supervisor
On/O by
Supervisor
On/O by Digital
Input
Demand Limit by
Supervisor
— Digital input ON/OFF command enabling.
— Digital input cooling/heating command enabling.
— Supervisor ON/OFF command enabling.
— Supervisor cooling/heating command enabling.
— Supervisor demand functionality enabling. (If enabled, the power request is
acquired not via a temperature probe and work set, but via Modbus serial data).
— Modbus serial data maximum cooling power limit enabling.
— Double setpoint use enabling. If enabled via the ID3 digital input, if the setpoint
is selected (contact open = normal setpoint, contact closed = double setpoint)
— Pump heater alarm enabling. (SLAVE ONLY)
— Enabling at switching o of the evaporator pump with the compressor o rela-
tive to the pump output of the individual slave cards. (SLAVE ONLY)
Adjusting temperature monitor
1
4/8 10:40:53
5.0
R1234ze
2
600
s
0
°C
°C
PI
INSTALLER
Master
Outlet
Glycolated Water
Freezing Temp.
Electronic Valve
Number
Regulation
Probe
Glycolated Water
Management
Refrigerant Gas
Regulation
Band
Regulation Type
Regulation
Temperature
Integration
Time
1
4/8 10:41:26
5.0
R1234ze
2
600
s
0
°C
°C
P
INSTALLER
Master
Glycolated Water
Freezing Temp.
Electronic Valve
Number
Regulation
Probe
Glycolated Water
Management
Refrigerant Gas
Regulation
Band
Regulation Type
Regulation
Temperature
Integration
Time
Inlet
