29
14.6 CONDENSER WATER INLET/OUTLET TEMPERATURE
MONITOR
U:1
(U9):
(U10):
40.0 °C
35.0 °C
TUWH
TIWH
Analog inputs
TUWH (U9): condenser water outlet temperature
TIWH (U10): condenser water inlet temperature (master)
14.7 CONDENSER WATER OUTLET MONITOR
U:2
(B9):
(B10):
40.0 °C
35.0 °C
TUWH
TUWHC
Analog inputs
TUWH (U9): condenser water outlet temperature
TUWHC (U10): common condenser water outlet temperature (slave)
14.8 ANALOGUE OUTPUT VOLTAGE VALUE MONITOR
U:1
00.0 V
Y0:
Analog inputs
Voltage value at analogue output Y0 and Y1.
14.9 SOFTWARE STATUS MONITOR
Aermec WFN
0.0.15
08/09/21
Software Version:
Release Date:
Software version and version date.
14.10 COMPRESSED STATUS MONITOR A
0000 RPM
0000 RPM
OK
00000
Speed Set.
Speed
Gas Type
Env.Status
Env.Zone
stopped
Speed set from card setpoint
No. of revs read by the compressor
Status: Stopped, Start, On, Switch o, war IN, war OUT, alarm
Envelope zone: OK, SLDL, SL, SLDH, DH, SHDH, SH, SHDL, DL
Type of gas set in the compressor
14.11 COMPRESSED STATUS MONITOR B
N
N
N
N
N
N
N
Coast
Al
Enab
Warn
OnRef
Run
Start
This mask is used to view the compressor status summary.
14.12 COMPRESSED STATUS MONITOR C
00.0 °C
000.0 °C
0000 s
0000 s
00.0 °C
Inverter Input:
Suction T.
Discharge T.
Oiltemp.
Min On Time
Min O Time
Intake temperature read by the compressor
Delivery temperature read by the compressor
Oil temperature read by the compressor
Minimum operating time remaining
Minimum switching o time remaining
