34
— Supervisor ON/OFF command enabling
— Supervisor cooling/heating command enabling
18.8 SUPERVISOR FUNCTIONALITY ENABLING MONITOR
Y
N
Demand by Supervisor
Demand Limit
by Supervisor
Supervisor demand functionality enabling (MASTER ONLY).
If enabled, the power request is acquired not via a temperature probe and work
set, but via Modbus serial data. Modbus serial data maximum cooling power limit
enabling.
18.9 DOUBLE SETPOINT ENABLING MONITOR
Y
Enable double setpoint
Double setpoint use enabling (MASTER ONLY).
If enabled via the ID3 digital input, if the set is selected (contact open = normal
setpoint, contact closed = double setpoint)
18.10 HEATER ALARM ENABLING MONITOR
N
N
Circuit breaker
Pump o
with compressor
— Pump thermal alarm enabling (SLAVE ONLY).
— Enabling at switching o of the evaporator pump with the compressor o rela-
tive to the pump output of the individual slave cards
18.11 ADJUSTING TEMPERATURE MONITOR
Master
Regulat.
temperature
Type
Reg.probe
OUTLET
Adjusting temperature selection (MASTER ONLY):
— INLET: Water inlet
— OUTLET: Water outlet
Selection of the adjustment probe position if OUTLET:
— Master: the UV output or CN output of the Master card is used
— Common: Probe B3 of slave 1 located on the evaporator exhaust manifold or
probe B10 of slave 1 located on the exhaust manifold is used
18.12 TYPE OF ADJUSTMENT MONITOR
0600s
PI
regulation type
Type
Integration t.
— Type of adjustment (MASTER ONLY) PROP = proportional, INT = integral, PI =
proportional + integral.
— Integration time valid for PI or INT adjustment
18.13 THERMOSTAT ADJUSTMENT MONITOR
05.0 °C
Temperature band
Proportional band for the adjustment of the work thermostat (MASTER ONLY).
