TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
Additional data can be found in the Operator’s Manual for electric adjustable
aircraft propeller SR 2000.
WARNING
Never run the engine without propeller, this inevitably causes
engine damage and is an explosion hazard.
1.6.10.4 Engine bed
The engine bed is welded from chrome-molybdenum tubes and its producing is
different for an aeroplane model with a fixed undercarriage or for an aeroplane model
with a retractable undercarriage.
1.6.10.4.1 Engine bed for fixed undercarriage
The engine bed is solid and attached to the firewall with 4 bolts. The bed is spring-
mounted with four rubber silentblocks.
1.6.10.4.2 Engine bed for retractable undercarriage
The engine bed is two-part type. A front part is attached to the engine and with a rear
part is spring-connected with rubber silentblocks and 4 bolts. The rear part is attached
to the firewall and this part serves for attachment of the retractable nose wheel leg.
