TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
2. Mark the neutral position of the elevator trailing edge.
3. Fully pull and push the control stick to deflect the elevator and mark the positions of
deflected elevator trailing edge.
4. Measure the distances between marks at a half of the elevator on the hard drawing paper
by means of a ruler.
5. Compare, if measured deflections correspond with those ones specified in Control
Surfaces Deflections Record.
7. If not – adjust elevator deflections with adjustable end of rod according to the par 3.11.2
2.3.5 Rudder deflections measurement
Measurement procedure:
1. Insert a hard drawing paper in a space between a rudder and a fuselage aft part and
hold the drawing paper to the fuselage bottom below rudder by means of the adhesive
tape.
2. Mark the neutral position of the lower rudder trailing edge on a hard drawing paper.
3. Fully deflect the rudder and mark the position of a deflected lower rudder trailing edge
on a hard drawing paper.
4. Measure by means of a ruler distance between the mark on a hard drawing paper.
5. Compare, if measured deflections correspond with those one in Control Surfaces
Deflections Record. Record real values into the Record.
Date: 01.03.2002 WT-9 Dynamic Section 2 Page 2 - 9
