TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
SECTION 2
OPERATION
Page
2.1 Operation outlines 2-2
2.2 Aeroplane assembly 2-2
2.2.1 Wing 2-2
2.2.1.1 Necessary tools 2-2
2.2.1.2 Wing assembly and disassembly procedure 2-2
2.2.2 Landing gear 2-3
2.2.2.1 Fixed undercarriage 2-3
2.2.2.1.1 Tire replacement 2-3
2.2.2.1.1.1 Necessary tools 2-3
2.2.2.1.1.2 Main landing gear wheel 2-3
2.2.2.1.1.3 Nose wheel 2-5
2.2.3 Cockpit canopy 2-6
2.2.3.1 Canopy demounting 2-6
2.2.3.2 Canopy mounting 2-6
2.2.4 Instrument panel 2-6
2.3. Measurement of control surfaces deflections 2-7
2.3.1 Required deflections 2-7
2.3.2 Aileron deflections measurement 2-8
2.3.3 Wing flap deflections measurement 2-8
2.3.4 Elevator deflections measurement 2-8
2.3.5 Rudder deflections measurement 2-9
2.4 Permissible plays 2-10
2.5 Weighing the aeroplane and C.G. calculation 2-11
2.5.1 Empty weight determination 2-11
2.5.2 Operating C.G. range calculation 2-11
2.6 Ground handling 2-12
2.6.1 Towing the aeroplane 2-12
2.6.2 Parking the aeroplane 2-12
2.6.3 Mooring the aeroplane 2-12
2.6.4 Jacking the aeroplane 2-12
2.7 Road transport 2-13
