Aerospool WT-9 Dynamic - SECTION 1 TECHNICAL DESCRIPTION

TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
SECTION 1
TECHNICAL DESCRIPTION
Page
1.1 Introduction 1-3
1.2 Certification basis 1-3
1.3 Warnings, cautions and notes 1-3
1.4 Basic and general information 1-3
1.4.1 Aeroplane description 1-3
1.4.2 Designation 1-3
1.5 Basic technical data 1-4
1.5.1 Aeroplane views 1-4
1.5.2 Three-view drawing 1-5
1.5.3 Basic dimensions 1-6
1.5.4 Weights 1-6
1.5.5 Centre of gravity 1-7
1.5.6 Operating limitations 1-7
1.6 Technical description of the aeroplane 1-7
1.6.1 General 1-7
1.6.2 Fuselage 1-7
1.6.3 Wing 1-7
1.6.3.1 Aileron 1-8
1.6.3.2 Wing Flap 1-8
1.6.4 Horizontal tail unit 1-8
1.6.5 Vertical tail unit 1-8
1.6.6 Landing gear 1-8
1.6.6.1 Fixed undercarriage 1-8
1.6.6.2 Retractable undercarriage 1-9
1.6.6.3 Nose wheel leg 1-10
1.6.6.4 Retractable undercarriage system 1-11
1.6.6.5 Wheel brakes system 1-12
1.6.7 Cockpit 1-13
1.6.7.1 Cockpit control 1-13
Date: 01.03.2002 WT-9 Dynamic Section 1 Page 1 - 1
