TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
2.2.3 Cockpit canopy
2.2.3.1 Canopy demounting
Apply the following procedure to demount the cockpit canopy:
1. Open canopy should be supported.
2. Dismantle both gas struts. The securing shim sweep into a open position for the
releasing of the strut joint pin.
3. Unscrew self-locking nuts of the front canopy hinges which are located in the cockpit.
4. Remove the canopy attachment screws.
5. Carefully remove the canopy.
WARNING
Be carefully at canopy handling on the ground of a possibility a
damage of the Perspex canopy.
2.2.3.2 Canopy mounting
The mounting procedure is opposite to the demounting one and does not require
additional explanation.
2.2.4 Instrument panel
The instrument panel is separated into two parts. The upper part of the instrument panel
contains the flight instruments and powerplant instrument and lower part contains the
powerplant controls. A sheet cover over the instrument panel removes after the releasing of
the connecting screws when install or de-install the instruments. The flight and navigation
instruments are mounted as an option of the customer ( but with respect to the weight
limitation and C.G. of the ultra light aircraft ). Follow the instructions of an instrument
manufacturer.
