TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
11. Remove outer rim half from the wheel axle.
12. Take the tire out.
13. Replace the tire or tube
14. Insert a new tube into a tire and slightly pump up.
15. Shoe the tire with tube, the valve insert into the hole.
16. Put the rim with tube and tire on the wheel axle and adjust the wheel hub.
17. Screw connecting screws both rim halves.
18. Adjust the tire and tube positions to avoid a tire nip.
19. Tighten the screws.
20. Put the washer on the axle.
21. Screw the castle nut on the axle, insert a new cotter pin and lock the castle nut.
22. Secure the connecting screws both rim halves.
23. Pump up the tube on a required wheel pressure.
24. Mount the wheel fairings back in the opposite sequence.
Fig.25 Disassembly of the main landing gear wheel (fixed undercarriage)
