TECHNICAL DESCRIPTION, OPERATING, MAINTENANCE AND REPAIR MANUAL
5.1 List of Appendices
5.1.1 Control Surfaces Deflections Record
Control Surfaces Deflections Record
WT-9 Dynamic Registration: S/N: Date:
Upward Downward Control surface
deflection
Specified Real Specified Real
Distance between the
measurement point
and the turning point
25°/ 106 mm
°
15°/65 mm
°
252 mm
Left aileron
Tolerance ±5 mm Tolerance ±5mm
25°/ 106 mm
°
15°/65 mm
°
252 mm
Right aileron
Tolerance ±5 mm Tolerance ±5 mm
28°/112 mm
°
18°/74 mm
°
240 mm
Elevator
Tolerance ±6 mm Tolerance ± 6mm
Right
Left
25°/135 mm
°
25°/135 mm
°
320 mm
Rudder
Tolerance ± 20mm Tolerance ±20mm
Real
Wing flap deflection
Specified
Right Left
1. Take off
15°/
76 mm
°
°
295 mm (root rib of
the outer wing )
2. Intermediate
24°/
120mm
°
°
295 mm (root rib of
the outer wing )
3. Landing
35°/
181mm
°
°
295 mm (root rib of
the outer wing)
Deflections tolerance ± 6 mm , maximum difference between both flaps deflection ± 6 mm
References and notes:
Measurement carried out by:
Signature:
Date: 01.03.2002 WT-9 Dynamic Section 5 Page 5 - 2
