5.1.7 Measurement Record – ZKM Encoding Altimeter
MEASUREMENT RECORD – ZKM
A/C Type: WT-9 Dynamic S/N: Registration:
Encoding altimeter
Type: S/N:
A. Transitions of the encoder (Feet)
Transition
altitude
Measured
error
climb
Measured
error
descent
Allowed
toleran.
Code
change
Transition
altitude
Measured
error climb
Measured
error
descent
Allowed
toleran.
Code
change
50 50 7950 xx
± 50
750 xx “ B1 8050 xx „
850 xx „ B1 9950 xx „
1950 Xx „ 10050 xx „
2050 xx „ 14750 xx „ A1
2750 “ A4 14850 xx “ A1
2850 xx “ A4 15950 xx “
3950 Xx “ 16050 xx “
4050 xx “ 19950 xx “
4950 Xx “ 20050 xx “
5050 xx “ 24950 xx “
5950 Xx “ 25050 xx “
6050 xx “ 29950 xx “
6750 Xx “ A2 30050 xx “
6850 xx A2 34950 Xx
35050 xx
Code change: comply ( yes – no )
B. OTHERS TESTS
Tightness test Allowed tolerance
(measure at 4000 feet) is
-100 feet
Measured deviation
C. TOTAL ASSESSMENT: comply ( yes – no )
Record elaborated by :
Date:
Record approved by :
Date:
Measurement carried out by:
Date:
