When stopping first the power supply to the gas solenoid valve is interrupted, and then the supply to the ignition and rev regulator is
interrupted.
In manual activate first the start and then the fuel pump button to supply EV GAS and Ignitions.
2.11.6. RESET (out 28)
Plants managed by remote control require a control that can reset circuits or close switches.
When output 28 is set to RESET, each time the RESET command is given via the button or remote control, output 28 is active.
2.11.7. DOUBLE STARTING (out 28) UNI 9490 NFPA NFS61.940
This allows an automatic switch over to a second starter battery.
The number of starts set under time settings is spread over the two batteries alternately. If,
at the end of the cycles, the motor has not started, an alarm is raised for no start having
occurred.
Note: for the adjustment to the rules of safety fireproof, the “FORCED RUNNING” can be required, to see 2.10.5
2.11.8. ANTI-THEFT PROTECTION
Only on M02 with a serial RS232C output.
This is only active on plants that are fitted with remote controls. If
the generator is disconnected an alarm is raised and transmitted via
modem or GSM. Each alarm is stored in the alarm history file.
Operation
When the generator circuits relating to the 30A R1 relay, that
isolates the battery cables are interrupted, and wire 12 that activates
the burglary alarm status is disconnected, the power supply to the
M02 is maintained by battery 2 that powers the remote control
system and sends the burglary alarm message.
Programming:
Under Misc. Settings, set High Oil Temperature alarm (12) to “Anti-
Burglary).
