2.13. SELF-PROGRAMMING
The GCM02 module is capable of programming itself.
This function is very useful where wrong configuration of a board could give rise to conflicts in operational terms. The self-programming
function allows all the setting fields to be reset to comply with a table of standard preset values. These must then be adapted to suit the
plant’s working parameters, but they do provide a specific starting point for configuring the board.
In order to allow self-programming, shut down the programming commutator, by pressing the “ +” and “Enter” keys together for 8
seconds. After this time the display will read “SELF-PROGRAMMING” and the board will configure itself using the parameters shown in
the table below:
N° DESCRIPTION DEFAULT VALUE VARIATION
1 TA ratio ....../ 5A 1000
2 Fuel level (100% = full) 100%
3 Motor temperature 130 °C
4 Number of starts 4
5 Starting and pause times 5”
6 Mains power supply activation delay 1’
7 Generator activation delay 5
8 Starting delay 0”
9 Stop delay 60”
10 Differential intervention 0,1”
11 Generator overload delay 60”
12 PRC – glow plug pre-heating time 20”
13 EJP delay 0’
14 Alternating generator changeover delay 4 h
15 Three-phase or single-phase Three-phase
16 Maximum mains power supply voltage 450V
17 Minimum mains power supply voltage 320V
18 Maximum mains power supply frequency 60Hz
19 Minimum mains power supply frequency 40Hz
20 Maximum generator voltage 450V
21 Minimum generator voltage 320V
22 Maximum generator frequency 60Hz
23 Minimum generator frequency 40Hz
24 Maximum generator current (Ig). 1024A
25 Generator short circuit 3072A
26 Motor start Hz 17 Hz
27 Maximum battery charge voltage 13,5-27 V
28 Maximum battery charge current 6 A
29 Pump level ON = > 30%
30 Pump level OFF = < 80%
31 Fuel reserve level = >10%
32 Minimum oil pressure 1,5 bar
33 Maximum motor temperature 130°C
34 Differential activation current 300 mA
35 Maximum mains power supply current 1000A
36 Working hours before service request 0 = excluded
37 Energy return - 0 KW = excluded
38 Pre-heating out (CONNECTION 28) Pre-h. motor
39 Automatic test (the clock must be set) Inactive
40 Time of automatic test 13,00
41 Duration of automatic test 3’
42 Automatic cut-out OFF
43 Phase sequence Off
44 Special functions Cut-out
45 Anti-burglary Oil temp.
46 Name and telephone number Not changed
47 Current transformers On generator
