AEZ GCM02 - Connections on the Mp02 Power Unit

FILE VER LAST ISSUE LANG. PAGE
GCM02-MT-ING4 NEW.doc c/02 04/03/2003 ENG Page 43 of 57
2.14.2 CONNECTIONS ON THE MP02 POWER UNIT
This entails 6.3 mm. 54 terminals and a 25 poles connector for connections between the GC M02 module and the MP02.
The faston connections used for isolated terminals can take conductors of up to 6 mm
2
.
The wiring of the terminal board that is also illustrated on the safety guard respects the numbering indicated in the table below:
Terminal
no.
DESCRIPTION
USAGE LIMITS INPUT/OUTPUT
1 0-32V 16 A (+Batt) board power supply 30 A I
2 0-32V 16 A (-Batt) board power supply 30 A I
3 Bridge for 12V power supply
4 Bridge for 12V power supply
5 +B 30 A max starting command output 30 A O
6 +B 30 A max stop command output 30 A O
7 (15/54) +B 16 A max utilities command output 16 A O
8 100 mA max. alarm output 200 mA DC O
9 Lower oil pressure alarm input Negative/positive
I
10 0-32V battery charger generator input Negative I
11 High water temperature alarm input Negative/positive
I
12 Oil temperature alarm input Negative I
13 Fuel reserve alarm input Negative I
14 Water level alarm input Negative I
15 Fuel level transducer input
0-300Ω
I
16 Motor temperature transducer input
0-300Ω / 0-10V
I
17 Oil pressure transducer input
0-300Ω / 0-10V
I
18 EJP / RES/TEST function input (programmable) Negative I
19 Emergency input Negatieo I
20 LOCK/FORCED STARTING function input Negative/positive
I
UTILITIES CONNECTIONS
21-22 Secondary 16/29V ac battery charger transformer 8 A I
23 Overload alarm contact 10 A I
24 Main contact maker ON indication input Negative I
25 Generator contact maker ON indication input Negative I
26-27 12 or 24V fuel pump contact maker command = 200 mA DC O
26-28 12 or 24V pre-heating contact maker command = 200 mA DC O
29-30 Toroid for differential protection, reading coil. I
31-32 Toroid for differential protection, test coil. I
AMPEROMETRIC TRANSFORMERS
33 Input TA / 5 A phase X 3000/5 A I
34 Input TA / 5 A phase Y 3000/5 A I
35 Input TA / 5 A phase Z 3000/5 A I
36 Input TA / 5 A mutual 20 A 2” I
SWITCHING COMMAND
37 Mutual CR 10 A 250V ac
38 NO 10 A CR command contact 10 A 250V ac O
39 NC 10A CR command contact 10 A 250V ac
40 NO/NC configurable contact to command GE switch opening 10 A 250V ac
41 NO/NC configurable contact to command GE switch opening 10 A 250V ac
42 Mutual CG 10 A 250V ac O
43 NO 10A CG command contact 10 A 250V ac O
44 NC 10A CG command contact 10 A 250V ac
POWER SUPPLIES
45-46 Primary 220Vac battery charger transformer. 100-500Vac O
47 Mains neutral 0-600Vac I
48-49-50 Mains R, S, T phases 100-600Vac I
51 Generator neutral 0-600Vac I
52-53-54 Generator X, Y, Z phases 100-600Vac I
