Afinia H800+ 3D Printer User’s Manual
11
Loading the 500g Filament Spool
A. Insert the end of filament into one end of the Filament tube,
which is on the upper right side of the spool holder.
B. Feed the filament through the tube until about 4 inches of
filament protrudes from the tube.
C. Put the Filament Spool onto the holder with the end of the filament pointing up from the
back.
D. Feed the filament into the extruder head as far as it can go
(about 2 inches) using the feed tube just behind the fan.
E. Long Press the Filament button.
a. If the filament doesn’t start feeding when the
printer beeps, gently push in the filament.
F. Replace the magnetic filament cover.
