Afinia H800+ 3D Printer User’s Manual
19
Status
This area displays the current temperature of the nozzle and platform and if either element is
currently being heated.
Nozzle & Platform Position Controls
The five buttons (FL, FR, Center, NL, NR) control the position of the nozzle and the platform.
The To button controls the height of the platform, and is used in the manual nozzle height
calibration procedure described on page 17.
Bottom returns the platform to the lowest position.
Set Nozzle Height
Uses the value in the To box and saves it as the Nozzle Height.
Stop All
Stops heating and all the movement of the printer. Once you click this button, the current model
being printed is cancelled.
You CANNOT resume a print job once the printer has been stopped.
Pause Print
This button will pause a print in mid-progress while allowing you to resume the print job where it
left off. This is useful if you want to change the material color mid-print or to allow fasteners to be
inserted into printed cavities and then printed over to lock the fastener into place.
This option is only available when the printer is printing and above the first four printed layers.
Table Heat 1 hr
Click the Table Heat 1 hr button to heat the table for a full hour to the correct temperature for the
selected filament type.
The Status bar will show the
progress of the platform heating.
Heating the platform will not take the full hour, but the longer the platform heats, the more the outer
edges of the platform will be heated. For prints extending close to the edge of the platform, this will
help prevent warping of the model during printing.
Note: You should always preheat the platform prior to printing to ensure the best results.
Stop Preheat (Windows) / Stop Heat (Mac)
This button halts any heating of the table, either the 1 hour heat or the 15 minute preheat from the
3D Print menu or control panel.
This option only appears when the table is being heated.
