AGI HI ROLLER - 3 Conveyor Components; Operator Orientation; Component List

HI ROLLER - BELT CONVEYORS 3. CONVEYOR COMPONENTS
HI ROLLER, MINI ROLLER, LO ROLLER & HI LIFE 3.1. OPERATOR ORIENTATION
P115506 R3 17
3. Conveyor Components
3.1. OPERATOR ORIENTATION
3.2. COMPONENT LIST
• Head Sections and Discharges
• Motor and Drive Mountings
• Trunking Sections
• Covers
• Loaders/Inlets
•V-Plow
• Tail Sections
• Take-Up Sections
FITTED WITH CLAMPS
FOR A NORTH
AMERICAN MARKET
FITTED WITH CLAMPS FOR AN
INTERNATIONAL MARKET
STANDARD ORIENTATION: TO DETERMINE
RIGHT AND LEFT, STAND BY TAIL SECTION
AND LOOK TOWARD HEAD SECTION.
REVERSIBLE CONVEYOR ORIENTATION: TO DETERMINE
RIGHT AND LEFT, STAND AT NON-DRIVE SECTION, AND
LOOK TOWARD DRIVE END SECTION.
