HI ROLLER - BELT CONVEYORS 4. APPLICATION DESIGN CONSIDERATIONS
HI ROLLER, MINI ROLLER, LO ROLLER & HI LIFE 4.3. DISCHARGE CONSIDERATIONS
P115506 R3 29
• take-up section - clearance to access take-up rods
• head section - much wider than standard trunking sections
• motor and drive - depending on type, much wider than head section
• tripper sections - much wider than standard trunking sections
• bottom clearances for cleaning and bottom removal
• inspection doors and top cover removal
• tail cover and inspection door removal
4.3. DISCHARGE CONSIDERATIONS
• Spouting angles: Materials flow differently in spouting. The proper angle
must be maintained so that the material will freely flow in the spout.
• Spouting sized properly: Flow characteristics are different for each type of
material. Properly sized spouting must be installed to handle the capacity of
the discharge flow from the conveyor.
4.4. INCLINES
• Gradual: Hi Roller Conveyors can be installed with a gradual up-bend. This is
the lowest cost, horsepower, and maintenance option. Hi Roller's engineering
department must complete design calculations to determine the amount of
gradual up-bend that can be installed on a specific application.
• Sharp up-bends: Hi Roller Conveyors can be installed with a sharp up-bend
section. This is the highest cost, horsepower, and maintenance option. Hi
Roller's engineering department must complete design calculations to deter-
mine the amount of increased horsepower and cost of this option for a spe-
cific application.
• Horsepower: Inclined conveyors of any type require additional horsepower.
A straight, gradual or sharp up-bend inclined conveyor will require additional
horsepower to simply lift the material. This additional horsepower will be cal-
culated by Hi Roller's engineering department.
• Capacity: Inclined conveyors of any type will not convey the same amount of
material as a flat horizontal conveyor. Hi Roller's engineering department will
calculate the capacity of a specific application.
4.5. TRUNKING INSTALLATION
Important: Trunking MUST be installed straight.
Check trunking installation with laser, transit, or wire line to ensure it is installed
in a straight line. Trunking that is not installed straight will cause belt tracking
problems.
