Agilent Technologies 1260 Infinity VL User Manual

128 1260 Infinity QuatPump VL User Manual
9 Maintenance
Reinstalling the Pump Head Assembly
Reinstalling the Pump Head Assembly
When When reassembling the pump
Tools required p/n Description
8710-2392 Hex key 4 mm15 cm long T-handle
Parts required p/n Description
79846-65501 Pump head grease
1 If needed, apply a small amount of grease on the back of
the screws. Normally, the grease added during
manufacturing is sufficient for a long time.
2 Slide the pump head assembly onto the pump drive and
use a 4 mm hexagonal key to tighten the pump head
screws stepwise with increasing torque (max. 5 Nm).
BZiZg^c\Yg^kZ
Ejbe]ZVY
Ejbe]ZVYhXgZlh
