1260 Infinity QuatPump VL User Manual 37
Installing the Pump
3
Connecting Modules and Control Software
Connecting Modules and Control Software
Connecting Modules
1 Place the individual modules in a stack configuration as shown in Figure 4
on page 32.
2 Ensure the power switches on the front of the modules are OFF (switches
stand out).
3 Plug a CAN cable into the CAN connector at the rear of the respective
module (except vacuum degasser).
4 Connect the CAN cable to the CAN connector of the next module, see
Figure 5 on page 33.
5 Press in the power switches to turn on the modules.
Use of unsupplied cables
Using cables not supplied by Agilent Technologies can lead to damage of the
electronic components or personal injury.
➔ Never use cables other than the ones supplied by Agilent Technologies to ensure
proper functionality and compliance with safety or EMC regulations.
