32 1260 Infinity QuatPump VL User Manual
3 Installing the Pump
Optimizing the Stack Configuration
Figure 4 Recommended Stack Configuration for 1260 Infinity (Front View)
Solvent cabinet
Pump
Autosampler
Detector
Thermostatted
column compartment
Instant Pilot
