7 Referring to the graphics that follow, note problems with
the power supply, then return to Figure 2, “16901A Power
Troubleshooting Flowchart,” on page 28.
Power Supply Test Points
+5
GND
+12
-12
+3.3
-5.2
-3.25 (slot A)
-3.25 (slot B)
