71
Chapter 3 Front-Panel Menu Operation
To Output a Burst Waveform
4
3
4 Set the burst period.
Press the Burst Period softkey and then set the period to 20 ms using the
numeric keypad or the knob and cursor keys. The burst period sets the
time from the start of one burst to the start of the next burst (note the
display icon).
At this point, the waveform generator outputs a continuous three-cycle
burst at 20 ms intervals.
You can generate a single burst (with the specified count) by pressing
the
key. For more information, see “To Trigger a Sweep or Burst”
on page 72.
You can also use the external gate signal to create gated bursts, where a
burst is produced while a gate signal is present on the input.
