... Continued from previous page
External DMM Ohmmeter Connections
Test
#
Channels
Closed*
HI LO
HI
Sense
LO
Sense
Measured Value
Test
Limit
Relay
Measured
16 Ch 16 & 6 P3 P3 P1 P1 __________ Ohms
2.00Ω
K306
17 Ch 16 & 7 P3 P3 P1 P1 __________ Ohms
2.00Ω
K307
18 Ch 16 & 8 P3 P3 P1 P1 __________ Ohms
2.00Ω
K308
19 Ch 16 & 9 P3 P3 P1 P1 __________ Ohms
2.00Ω
K309
20 Ch 16 & 10 P3 P3 P1 P1 __________ Ohms
2.00Ω
K310
21 Ch 16 & 11 P3 P3 P1 P1 __________ Ohms
2.00Ω
K311
22 Ch 16 & 12 P3 P3 P1 P1 __________ Ohms
2.00Ω
K312
23 Ch 16 & 13 P3 P3 P1 P1 __________ Ohms
2.00Ω
K313
24 Ch 16 & 14 P3 P3 P1 P1 __________ Ohms
2.00Ω
K314
25 Ch 16 & 15 P3 P3 P1 P1 __________ Ohms
2.00Ω
K315
26 Ch 16 & 15 P3 P3 P4 P4 __________ Ohms
2.00Ω
—
27 Subtract (Test 26 – Test 25) __________ Ohms
2.00Ω
K316
* Only the channels currently under test should be closed at one time. All other channels should be open.
Chapter 4 Calibration Procedures
Relay Verification
100
