4-50 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Making a Measurement
Stress Force
The following illustrates the basic procedures for stress forcing.
1. Connecting your DUT to the
4155B/4156B. See “Connecting DUT” on
page 4-3 for procedures.
2. Defining the stress units and constant
output units. The following tasks are
described:
•“To Set up Stress Source Channels” on
page 4-51
•“To Use Selector” on page 4-60
3. Setting the stress forcing parameters and
constant output value. The following tasks
are described:
•“To Set up Stress Condition/Timing”
on page 4-53
•“To Set up ac (Pulse) Output” on page
4-55
•“To Set up dc Output” on page 4-57
4. Executing the stress forcing. The
following task is described in “To Force
Stress” on page 4-58.
To Next Page
