6-74 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Screen Organization
STRESS Screen Group
STRESS Screen Group
STRESS screen group has the following screens:
Stress channel definition: For defining the stress channels of the 4155B/4156B,
setting up SMU/PG selector, and setting up the trigger.
Stress setup: For setting the stress parameters.
Stress force: For monitoring the progress of stress forcing.
To move into the STRESS screen group, do the following:
• Press Stress front-panel key in the PAGE CONTROL key group.
Then the following softkeys appear in the primary softkey area:
CHANNEL STRESS STRESS PREV NEXT
DEF
SETUP FORCE PAGE PAGE
• Select CHANNEL DEF softkey to move to the STRESS: CHANNEL
DEFINITION screen.
• Select STRESS SETUP softkey to move to the STRESS: STRESS SETUP
screen.
• Select STRESS FORCE softkey to move to the STRESS: STRESS FORCE
screen.
When you press the
Stress front-panel key in the MEASUREMENT key group, the
STRESS: STRESS FORCE screen appears and stress forcing starts.
