4-10 Agilent 4155B/4156B User’s Guide Vol.2, Edition 5
Making a Measurement
Sweep Measurements
Sweep Measurements
This section describes the sweep measurement tasks.
The basic procedure to test your DUT is as follows:
1. Connecting your DUT to the
4155B/4156B. See “Connecting DUT” on
page 4-3 for procedures.
2. Defining measurement mode and
measurement units that you use to make
measurement.
The following tasks are described:
•“To Define Measurement Units”
•“To Define a User Function”
•“To Use R-Box”
3. Setting the source parameters of the
units. The following tasks are described:
•“To Set up Primary Sweep”
•“To Set up Secondary Sweep”
•“To Set up Synchronous Sweep”
•“To Set up Constant Output”
•“To Set up SMU Pulsed Output”
•“To Set up PGU Output”
To Next Page
