1.
T
o
select
the
Z-

mode
,
OUTPUT
717;":SENS:FUNC
'FIMP'"
OUTPUT
717;":CALC1:FORM
MLIN"
OUTPUT
717;":CALC2:FORM
PHAS"
T
o
select
the
R-X
mode
,
OUTPUT
717;":SENS:FUNC
'FIMP'"
OUTPUT
717;":CALC1:FORM
REAL"
OUTPUT
717;":CALC2:FORM
IMAG"
2.
T
o
select
the
Y-

mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT
717;":CALC1:FORM
MLIN"
OUTPUT
717;":CALC2:FORM
PHAS"
T
o
select
the
G-B
mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT
717;":CALC1:FORM
REAL"
OUTPUT
717;":CALC2:FORM
IMAG"
3.
T
o select
the Cp-D
mode
,
OUTPUT
717;":SENS:FUNC 'FADM'"
OUTPUT
717;":CALC1:FORM
CP"
OUTPUT
717;":CALC2:FORM
D"
T
o select
the Cp-Q
mode
,
OUTPUT
717;":SENS:FUNC 'FADM'"
OUTPUT
717;":CALC1:FORM
CP"
OUTPUT
717;":CALC2:FORM
Q"
T
o
select
the
Cp-G
mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT
717;":CALC1:FORM
CP"
OUTPUT
717;":CALC2:FORM
REAL"
T
o
select
the
Cp-Rp
mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT
717;":CALC1:FORM
CP"
OUTPUT
717;":CALC2:FORM
RP"
4.
T
o
select
the
Cs-D
mode
,
OUTPUT
717;":SENS:FUNC
'FIMP'"
OUTPUT
717;":CALC1:FORM
CS"
OUTPUT
717;":CALC2:FORM
D"
T
o
select
the
Cs-Q
mode
,
OUTPUT
717;":SENS:FUNC
'FIMP'"
OUTPUT
717;":CALC1:FORM
CS"
OUTPUT
717;":CALC2:FORM
Q"
T
o
select
the
Cs-Rs
mode
,
OUTPUT 717;":SENS:FUNC
'FIMP'"
OUTPUT
717;":CALC1:FORM
CS"
OUTPUT
717;":CALC2:FORM
REAL"
5.
T
o
select the
Lp-D mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT 717;":CALC1:FORM
LP"
OUTPUT
717;":CALC2:FORM
D"
T
o
select the
Lp-Q mode
,
OUTPUT
717;":SENS:FUNC
'FADM'"
OUTPUT 717;":CALC1:FORM
LP"
OUTPUT
717;":CALC2:FORM
Q"
To select the Lp-G mode
,
OUTPUT 717;":SENS:FUNC 'FADM'"
OUTPUT 717;":CALC1:FORM LP"
OUTPUT 717;":CALC2:FORM REAL"
To select the Lp-Rp mode
,
OUTPUT 717;":SENS:FUNC 'FADM'"
OUTPUT 717;":CALC1:FORM LP"
OUTPUT 717;":CALC2:FORM RP"
6.
To select the Ls-D mode
,
OUTPUT 717;":SENS:FUNC 'FIMP'"
OUTPUT 717;":CALC1:FORM LS"
OUTPUT 717;":CALC2:FORM D"
To select the Ls-Q mode
,
OUTPUT 717;":SENS:FUNC 'FIMP'"
OUTPUT 717;":CALC1:FORM LS"
OUTPUT 717;":CALC2:FORM Q"
To select the Ls-Rs mode,
OUTPUT 717;":SENS:FUNC 'FIMP'"
OUTPUT 717;":CALC1:FORM LS"
OUTPUT 717;":CALC2:FORM REAL"
4-6 Remote Operation (To Control from a Computer)
