4263B
Operation
Status
Register
The
Operational
Status
Register
group
provides
information
about
the
state
of the
4263B
measurement
system.
T
able
5-6.
Operation
Status
Condition
Register Assignments
Bit
No
.
Bit
W
eight
Description
10-15 Always
0 (zero)
9 512 BUF2
fullness
|
This
bit
is
set
when
the
BUF2
is
full.
8 256 BUF1 fullness
| This
bit is
set when
the
BUF1
is
full.
7 128 Correcting
|
This
bit
is
set
when
the
correction
data measurement
is in
progress
.
6 Always
0 (zero)
5 32 W
aiting
for
Trigger
|
This
bit
is
set
when
the
4263B
can
accept
a
trigger
.
4 16 Measuring
|
This
bit
is
set
when
the
4263B
is
actively measuring.
3 Always
0
(zero)
2 4 Ranging
|
This bit
is set
when the
4263B
is
currently
changing
its
range
.
1 2 Settling
|
The
4263B
is
waiting
for
signals it
controls to
stabilize enough
to
begin
a
measurement.
0 Always
0
(zero)
T
able
5-7.
Operation
Status
Event
Register
Assignments
Bit
No
.
Bit
W
eight
Description
10
-
15
Always
0
(zero)
9 512 This
bit
is
set
when
the
BUF2
has
become
full.
8 256 This
bit
is
set
when
the
BUF1
has
become
full.
7 128 This
bit
is
set
when
the correction
data measurement
has completed.
6 Always
0
(zero)
5 32 This bit
is set
when the
4263B
has
become
able
to
accept
a
trigger
.
4 16 This
bit
is
set
when
the measurement
has completed.
3 Always
0
(zero)
2 4 This
bit
is
set
when
the
ranging
has
completed.
1 2 This
bit is set when the settling has completed.
0 Always 0 (zero)
Questionable Status Register
The 4263B has no operation to report the event to the Questionable Status Register group
,
all
of whose bits are always 0. This register is available to keep consistency with other SCPI
compatible instruments.
5-44 GPIB Reference
