Change 7
Add TAR in 4 m Impedance Measurement Accuracy Test (Page 9-45) as follows.
Measurement:
Capacitance
Cable length:
4 m
Measurement time:
Long
Test signal level:
1 V
Status
PASS
Standard
Frequency [Hz]
Parameter Limits Result
1
Uncertainty
TAR
100 pF 1 k Cp ±0.19 pF
pF
± 0.0078 pF
25.29
100 pF 1 k D ±0.0019 ± 0.000065
29.32
1 nF 100 Cp ±0.002 nF
nF
± 0.000089 nF
22.18
1 nF 100 D ±0.0020 ± 0.000062
32.72
1 μF 100 Cp ±0.0018 μF
μF
± 0.000077 μF
23.73
1 μF 100 D ±0.0018 ± 0.000047
38.88
1 μF 1 k Cp ±0.0011 μF
μF
± 0.000071 μF
15.08
1 μF 1 k D ±0.0011 ± 0.000033
33.34
Note 1: Result = Measurement – Calibrated Value of Standard
Measurement:
Resistance
Cable length:
4 m
Measurement time:
Long
Test signal level:
1 V
Status
PASS
Standard
Frequency [Hz]
Parameter Limits Result
1
Uncertainty
TAR
100 mΩ
100
R ±0.84 mΩ mΩ ± 0.030 mΩ
28.84
100 mΩ
1k
R ±0.96 mΩ mΩ ± 0.030 mΩ
32.06
Note 1: Result = Measurement – Calibrated Value of Standard
Measurement:
DC Resistance
Cable length:
4 m
Measurement time:
Long
Test signal level:
1 V
Status
PASS
Standard Parameter Limits Result
1
Uncertainty TAR
100 mΩ R ±1.29 mΩ mΩ
± 0.030
mΩ
43.74
100 kΩ R ±0.87 kΩ kΩ ± 0.013 kΩ
68.26
Note 1: Result = Measurement – Calibrated Value of Standard
