41
Installation
Step 10. Attaching cryogenic liquid supplies
Figure 18. Location of cryogenic cooling valve
3. Connect the supply tubing to the liquid N
2
tank outlet with the fitting
recommended by the supplier.
4. Use a
SWAGELOK fitting to connect the supply tubing to the cryogenic valve
inlet.
Cryogenic cooling
valve
