Making SWAGELOK Connections
3. Push the tube fully into the female fitting, then withdraw it approximately
1–2 mm.
4. Mark the SWAGELOK fitting with a pencil line.
Front ferrule
Back ferrule
Nut
Insert tubing fully
Withdraw 1–2 mm
Tighten nut
