24 Installation and First Startup
1 Installation
Figure 3 Connecting and routing the cables
4 Slowly lower the front of the tray. Align the vial oven
access through- hole over the raised rim of the vial oven
access port. The tray front aligns with the front of the
instrument. The tray should be level and flat against the
instrument chassis.
Cable in clip
Cable connections
