38 Installation and First Startup

1 Installation

Depending on your hardware configuration, do one of the

following:

• Remove the valve cover (Figure 11). Completely loosen

the two T- 20 Torx screws, and remove the valve cover.

• Remove the valve/loop cover (Figure 12). Completely

loosen the three T- 20 Torx screws, and remove the

valve/loop cover.

Figure 11 The valve cover

Figure 12 The valve/loop cover

Valve cover
