Agilent Technologies 81101A User Manual

21
Introducing the Agilent 81101A Pulse Generator
Operating the Agilent 81101A
The Basic Screens
The major parameters for pulse generation can be set up in only two
screens.
The
Mode/Trigger screen
allows you to set the fundamental operating
and trigger modes with respect to the signal required.
Press the MODE/
TRG softkey to
access this screen.
In this screen, you can set up the signal to be triggered or continuous,
and to be a pulse stream or a burst (several pulses followed by a pause)
consisting of single or double pulses.
In the lower section you can specify the frequency source for the pulse
period and the trigger source.
*PulseStrm
Burst
OUTPUT TRG-LEVLIMITSMODE/TRG
CONTINUOUS
Single-Pulses at Out1
Pulse-Period: internal Osc
MODIFY
PULSES
