Using the Agilent 81101A
The Configuration Screen
The Configuration Screen
Use the Configuration screen to
set the GP-IB address of the Agilent 81101A,
perform a selftest,
select the frequency reference source and the frequency for the PLL.
To access the Configuration screen, press the CONFIG softkey. If the
CONFIG softkey is not displayed, press MORE.
GP-IB Address
Set the GP-IB address for the instrument in the range of 0 to 30. The
default address is 10.
Perform Operation
Selftest
Move the entry focus to P
ERFORM
: S
ELFTEST
and press the ENTER key.
If the selftest fails, a flashing E is displayed. Press HELP to see the list of
error messages.
10
TRG-LEV CONFIGMEMCARDLIMITS
Pulse-Period: internal PLL
GPIB-Address: 10
Group Params by: TIMING/LEVELS
PLL-Ref: Internal
MODIFY
Deskew 1: +0ps 2: +0ps
Perform Selftest:
µ
P and Signal
