Introducing the Agilent 81101A Pulse Generator
Operating the Agilent 81101A
Switching the Output On and Off
When you switch the instrument on, the output is switched off to protect
the device under test. The LED indicator next to the output connector
indicates the output state.
To switch the output on or off
either press SHIFT + 0 (ON/OFF),
or move the cursor to the ON/OFF parameter in the Output screen
and select the appropriate value by turning the knob.
Using the Special Function Keys
The instrument provides the following special function keys:
The MAN key can be used in triggered or gated mode to manually
trigger the instrument if there is no other source available (see The
Mode/Trigger Screen on page 44).
The STORE key can be used to store/recall to/from 1 to 9 individual
settings in the instrument memory.
In the internal memory location 0 there is a default setting stored.
Pressing SHIFT + STORE (RECALL) and selecting 0 resets the instrument to
the default setting.
The SHIFT key provides fast access to additional functions.
When the front panel controls are locked in remote control, pressing
the SHIFT key unlocks the front panel controls.
The HELP key provides access to the instruments on-line help or in
warning or error state, access to Warning/Error Report screen.
Pressing SHIFT + HELP (AUTOSET) sets the instrument to a valid
setting based on the current period setting.
