Agilent Technologies 81101A User Manual

36
Getting Started
Setting Up a Pulse Signal
To set the
timing parameters
as required:
1
Press the OUTPUT softkey to enter the Output screen.
2
Switch on the output.
3
Enter a period of 50
NS
.
A warning is shown, which you may ignore, because the parameter
conflict will be solved in the next steps.
4
Enter a pulse width of 30
NS
.
5
Enter 6
NS
for the leading edge.
6
For the trailing edge, select A
BSOLUTE
and enter a value of 10
NS
.
To set the
level parameters
as required:
1
Enter an offset of 1.65 V.
2
Enter an amplitude of 3.30 V.
ns
10.0
Per 50.00ns Normal ON
OUTPUT TRG-LEVLIMITSMODE/TRG
Delay
1
0.0ps
Width
LeadE
TraiE
30.00ns
6.00ns
10.0ns
Offset
Amplit
+0.0mV
1.00V
50 Ω
ΩΩ
Ω into 50.0 Ω
ΩΩ
Ω
MODIFY
V
3.30
Per 50.00ns Normal ON
OUTPUT TRG-LEVLIMITSMODE/TRG
Delay
1
0.0ps
Width
LeadE
TraiE
30.00ns
6.00ns
10.0ns
Offset
Amplit
+1.65V
3.30V
50 Ω
ΩΩ
Ω into 50.0 Ω
ΩΩ
Ω
MODIFY
