Using the Agilent 81101A

The Mode/Trigger Screen

In contrast to the previous figure, this figure shows a timing diagram

where the pulses are triggered by both rising and falling edges of the

arming source.

OUTPUT

TRIGGER OUT

Arming Source

(Trg'd by:)

Ext INPUT or MAN Key

Single Pulses

Double Pulses

STROBE OUT

Trg'd by:

Minimum Width
