Chapter 3 171
Softkey Menus
Menu Trees
Figure 3-7 CAL Key Menu Tree
* Changes to STOP ADJUST if FULL IF ADJ is pressed.
† Changes to STORE REF LVL if REF LVL ADJ is pressed.
‡ These functions are only available with firmware revisions >930809.
§
The CRT ADJ PATTERN key activates a pattern on the screen which is used
for adjusting the quadrature of the display. This pattern will appear in both
E-series and EC-series instruments. However, EC-series instruments do not
require adjustment and are not adjustable.
