200 Chapter4
Key Function Descriptions
Key Function Tables
CF STEP AUTO MAN AUTO COUPLE Adjusts the center frequency step size so
that when a step key is pressed, the center
frequency shifts by the selected step size.
CHAR SET 1 2 DISPLAY Accesses character sets used for creating
titles.
CLEAR WRITE A TRACE Clears trace A and sets it to accept and
display new input-signal data continuously.
CLEAR WRITE B TRACE Clears trace B and sets it to accept and
display new input-signal data continuously.
DETECTOR MODES TRACE Accesses a menu of detector modes.
DETECTOR NEG
PEAK
TRACE Selects negative-peak detection of the video
signal and places a D on the left side of the
display.
DETECTOR NORMAL TRACE The normal-detector mode alternately
displays positive and negative-peaks when
the presence of noise is detected, and
displays positive peaks otherwise.
DETECTOR POS PEAK TRACE Selects positive-peak detection of the video
signal and places a D on the left side of the
display.
DETECTOR SAMPLE TRACE Samples the video signal and places a D on
the left side of the display.
DISPLAY — Accesses a menu of display related
functions.
DLY SWP [ ] SWEEP Delays the start of the sweep until the
specified time elapses after the trigger
event (or before with Option 007.)
DLY SWP ON OFF SWEEP Turns on and off the function which delays
the start of the sweep until after the trigger
event. With Option 007 the sweep can be
started before the trigger event.
DSPL LIN ON OFF DISPLAY Switches the display line on and off.
EDGE POL POS NEG SWEEP Selects the polarity for edge triggering of a
gated measurement.
ERASE TITLE DISPLAY Erases the current title from the display.
Table 4-4 Control Functions
Control Keys Access Key Description
