496 Chapter7
Language Reference
IP Instrument Preset
DEMODULATION FM OFF; AM OFF
DEMODULATION TIME 1 second
DETECTOR NORMAL
DISPLAY LINE 0 dBm, OFF
EXT MIXER BIAS 0 mA, OFF
EXT MIXER LO
HARMONIC
6
FREQUENCY COUNTER OFF
FREQUENCY COUNTER
RESOLUTION
10 kHz
FREQUENCY DISPLAY ON
FREQUENCY MODE CENTER-SPAN
FREQUENCY OFFSET 0 Hz
GATE OFF
GATE CONTROL EDGE
GATE DELAY 3 µS
GATE LENGTH 1 µS
GATE POLARITY Positive
GRATICULE ON
INPUT ATTENUATION 10 dB, AUTO
MARKER MODE OFF
MAX MIXER LEVEL −10 dBm
MIXER INT
MIXER CONV LOSS 30.0 dBm, OFF
NOISE MARKER OFF
PEAK EXCURSION 6 dB
PEAK THRESHOLD −130 dBm
PRESELECTOR PEAK
TABLE
FACTORY DATA (not for 8560E/EC)
RBW to SPAN RATIO 0.011
REFERENCE LEVEL 0 dBm
REFERENCE LEVEL
OFFSET
0 dB, OFF
RESOLUTION BW 1 MHz, AUTO
SIGNAL
IDENTIFICATION
OFF
SIGNAL TRACK OFF
SPAN 2.9 GHz (8560E/EC) 6.5 GHz (Agilent
8561E/EC) 13.2 GHz (Agilent 8562E/EC) 26.5
GHz (Agilent 8563E/EC) 40 GHz (Agilent
8564E/EC) 50 GHz (Agilent 8565E/EC)
Table 7-7 8560 E-Series and EC-Series Preset States
Function State
